Product Description
-
Changeover switches, motor operated including a shaft, handle & bridging bars ( motor voltage Ue 110-240V AC/DC )
-
Rated Impulse Withstand Voltage (Uimp) : 12 kV
-
Rated Insulation Voltage (Ui) : 1000 V
-
Rated Operational Voltage : 1000 V
-
Motor Operational Voltage : 220 ... 240 V AC
-
Pollution Degree : 3
-
Handle Color : Black
-
Handle Type : Direct mounted handle
-
Switches Operating Mechanism : Mechanism at the End of the Switch
-
Distance Between Phases : Standard
-
Position of Line Terminals : Top In - Bottom Out, Bottom In - Top Out
-
Operating Mode : Front operated
-
Mounting Type : Base mounting
-
Number of Poles : 3
-
Degree of Protection : Front IP20
Product Specification
|
Rated Current (A) |
Product Id |
Type |
|
160 |
OTM160E3CM230C |
1SYN022845R8610 |
|
200 |
OTM200E3CM230C |
1SYN022845R8960 |
|
250 |
OTM250E3CM230C |
1SYN022845R9260 |
|
315 |
OTM315E3CM230C |
1SYN022847R1210 |
|
400 |
OTM400E3CM230C |
1SYN022847R1630 |
|
630 |
OTM630E3CM230C |
1SYN103567R1001 |
|
800 |
OTM800E3CM230C |
1SYN103570R1001 |
|
1000 |
OTM1000E3CM230C |
1SYN112677R1001 |
|
1250 |
OTM1250E3CM230C |
1SYN112676R1001 |
|
1600 |
OTM1600E3CM230C |
1SYN112678R1001 |
|
2000 |
OTM2000E3CM230C |
1SYN112709R1001 |
|
2500 |
OTM2500E3CM230C |
1SYN112710R1001 |
